Tanchjim Unveils Its First Flagship DAC: Tanchjim Luna on Flagship Chips

The device delivers high-quality sound thanks to two flagship CS43198 DACs from Cirrus Logic, which are used in premium-class audio players. These DACs ensure minimal distortion, high signal-to-noise ratio, and support high-resolution audio files up to 32-bit/768 kHz PCM and DSD256.
The Tanchjim Luna amplifier offers the ability to switch between Class AB and Class H modes, allowing optimization of power consumption and sound quality. The device’s maximum output power is 285 mW, making it compatible with headphones of various sensitivities. Tanchjim Luna is equipped with two headphone outputs: 3.5 mm and balanced 4.4 mm, allowing the user to choose the most suitable connector.

Tanchjim Luna Specifications:

• Headphone outputs: 3.5mm (single-ended), 4.4mm (balanced).
• Input: USB Type-C.
• Frequency range: 8Hz – 80kHz.
• Noise level: 1.3uV (balanced), 1uV (unbalanced).
• Dynamic range: 132dB balanced, 127dB unbalanced (AES17, 20kHz, A-weighted).
• Signal-to-noise ratio (SNR): 132 dB balanced (AES17, 20 kHz, A-weighted).
• Harmonic distortion coefficient (THD+N): 0.00014% (balanced).
• Output power:
  • 175 mW at 16 ohms (balanced),
  • 285 mW at 32 ohms (balanced),
  • 54 mW at 300 ohms (balanced).
• Output voltage:
  • 4VRMS (balanced high level),
  • 2VRMS (balanced low),
  • 2VRMS (unbalanced high level),
  • 1VRMS (unbalanced low level).
